Belangrike veiligheidsinstruksies
Lees asseblief alle instruksies sorgvuldig deur voor montering en gebruik. Bewaar hierdie handleiding vir toekomstige verwysing.
- Elektriese veiligheid: Ensure the power supply is disconnected before installation or maintenance. All electrical connections should be performed by a qualified electrician in accordance with local codes.
- Hantering: The mirror is made of tempered glass and is fragile. Handle with extreme care to prevent breakage and injury.
- Montering: This cabinet is designed for wall mounting. Ensure the wall structure can support the weight of the cabinet and its contents. Use appropriate mounting hardware for your wall type.
- Waterblootstelling: While the product is IP44 waterproof rated, avoid direct water spray onto electrical components.
- Kinders: Keep children away from the product during installation. Do not allow children to play with the cabinet.
Produk verbyview
The soges LED Aluminum Medicine Cabinet Mirror combines functionality with modern design, offering storage and intelligent lighting for your bathroom.
Sleutel kenmerke:
- Duursame konstruksie: Features a 4mm tempered aluminum mirror and aircraft-grade aluminum alloy frame.
- Smart Tri-Lighting System: Integrated LED strips with 3 color temperatures (Warm/Neutral/Daylight) and dimmable touch controls. Includes power-off memory function.
- Anti-mistegnologie: Full-surface anti-fog function automatically clears condensation within 30 minutes.
- Verstelbare berging: Inner adjustable shelves provide flexible storage options.
- Slow-Close Door: Equipped with slow-close hinges to prevent slamming.
- Waterdigte gradering: IP44 certification ensures resistance against water splashes and dust ingress.
- Veiligheid: Patent-backed driver system and shatterproof aluminum mirror.
Image: Key features of the soges LED Medicine Cabinet Mirror.
Spesifikasies
| Kenmerk | Detail |
|---|---|
| Handelsmerk | soges |
| Modelnommer | 10NBGLMC3047-NA |
| Produk Afmetings (D x B x H) | 5.1" D x 20" B x 28" H |
| Materiaal | Geharde glas, aluminium |
| Kleur | Swart |
| Item gewig | 21.12 pond |
| Weight Capacity (Maximum) | 88 pond |
| Aantal rakke | 6 (Verstelbaar) |
| Montage tipe | Muurmontering |
| Waterdigte gradering | IP44 |
| Beligtingsmodusse | 3-Color Changing (Warm, Neutral, Daylight) |
| Bykomende kenmerke | Anti-Fog, Dimmable, Power-Off Memory, Slow-Close Door |
Image: Product dimensions (5.1"D x 20"W x 28"H).
Pakketinhoud
Verifieer dat alle komponente teenwoordig en onbeskadig is voordat u met montering begin.
- LED Aluminum Medicine Cabinet Mirror
- Adjustable Glass Shelves (Quantity: 6)
- Montage Hardeware Kit
- Instruksie Handleiding
Opstelling en installasie
Follow these steps carefully for proper installation. It is recommended to have two people for installation due to the product's size and weight.
Gereedskap benodig (nie ingesluit nie):
- Boor
- Maatband
- Vlak
- Potlood
- Skroewedraaier
Installasie stappe:
- Berei die muur voor: Choose a suitable location on a sturdy wall. Use a level and pencil to mark the desired mounting height and positions for the hanging pieces.
- Install the Top Hanging Piece: Secure the top hanging bracket to the wall using appropriate screws and anchors. Ensure it is level and firmly attached.
- Install the Bottom Fixing Tray: Position the bottom fixing tray below the top bracket, ensuring it is level and aligned. Secure it to the wall.
- Fix the Top Hanging Piece: Carefully lift the medicine cabinet and hook it onto the top hanging piece. Ensure it is securely seated.
- Secure the Cabinet: Use the provided screws to fix the cabinet to the bottom fixing tray, preventing movement.
- Elektriese verbinding: Connect the cabinet's electrical wiring to your household electrical supply. This step must be performed by a qualified electrician. Ensure all connections are secure and insulated.
- Installeer rakke: Place the adjustable glass shelves inside the cabinet at your desired heights.
Image: Visual guide for installation steps.
Image: Interior features including adjustable shelves and soft-close hinges.
Bedryfsinstruksies
LED-beligtingsbeheer:
The mirror features a smart touch sensor for controlling the LED lighting.
- Krag aan/af: Lightly touch the power icon on the mirror surface to turn the LED lights on or off.
- Verander kleurtemperatuur: Double-touch the power icon to cycle through the three color temperatures: Warm Light, Neutral Light, and Cool Light (Daylight). The cabinet will remember your last setting when powered off and on.
- Pas Helderheid aan: When the lights are on, long-press the power icon to dim or brighten the LED lights. Release when the desired brightness is achieved.
Image: Smart touch sensor and 3 color lighting modes.
Image: Long press to adjust brightness.
Anti-mis funksie:
The mirror is equipped with an anti-fog function to maintain a clear reflection in humid conditions.
- Activate Anti-Fog: Lightly touch the anti-fog icon on the mirror surface to activate the defogging function.
- Outomatiese werking: The anti-fog function will automatically clear condensation within approximately 30 minutes.
- Deactivate Anti-Fog: Touch the anti-fog icon again to turn off the function.
Image: Anti-fog function in action.
Onderhoud & Versorging
Proper care will ensure the longevity and appearance of your medicine cabinet mirror.
- Maak die spieël skoon: Use a soft, lint-free cloth and a non-abrasive glass cleaner. Spray the cleaner onto the cloth, not directly onto the mirror, to avoid liquid seeping into electrical components.
- Maak die kabinet skoon: Wipe the aluminum frame and interior surfaces with a soft, damp lap. Vermy harde chemikalieë of skuurmiddels wat die afwerking kan beskadig.
- Afstof: Regularly dust the cabinet and mirror with a dry, soft cloth.
- Vermy oormatige vog: Although IP44 rated, avoid prolonged exposure to steam or direct water spray. Ensure the bathroom is well-ventilated.
- Rakversorging: The glass shelves can be removed for cleaning. Wash with mild soap and water, then dry thoroughly before replacing.
Probleemoplossing
If you encounter issues with your medicine cabinet mirror, refer to the following common problems and solutions.
| Probleem | Moontlike oorsaak | Oplossing |
|---|---|---|
| LED-ligte skakel nie aan nie. | No power supply; loose electrical connection; faulty touch sensor. | Check the main power switch. Verify electrical connections (consult a qualified electrician). Ensure the touch sensor area is clean and dry. |
| Anti-fog function is not working. | Anti-misfunksie nie geaktiveer nie; elektriese probleem. | Ensure the anti-fog icon has been touched to activate. Check power supply to the unit. |
| Lights flicker or change color unexpectedly. | Unstable power supply; touch sensor interference. | Ensure stable power. Clean the touch sensor area. Avoid touching the sensor with wet hands or objects. |
| Door does not close smoothly or slams. | Hinges require adjustment; obstruction. | Inspect hinges for damage or misalignment. Adjust hinges if necessary. Remove any obstructions preventing smooth closure. |
Indien die probleem voortduur nadat u hierdie oplossings probeer het, kontak asseblief kliëntediens.
Waarborg & Ondersteuning
No specific warranty information is provided in this manual. For warranty details, product support, or to purchase replacement parts, please contact soges customer service through their official webwebwerf of die kleinhandelaar waar die produk gekoop is.
Please have your model number (10NBGLMC3047-NA) and purchase date available when contacting support.
