Inleiding
Thank you for choosing the Auxmir 8-inch 30X/1X Double-Sided Magnifying Lighted Makeup Mirror. This manual provides essential information for the safe and efficient use of your new mirror. Please read it thoroughly before use and retain it for future reference.
Image: Auxmir 8-inch 30X/1X Double-Sided Magnifying Lighted Makeup Mirror, showcasing its sleek design and illuminated ring.
Produk verbyview
The Auxmir BM-2519 mirror features a double-sided design with 1X and 30X magnification, integrated LED lighting with three color modes, and adjustable brightness. It is rechargeable and designed for versatile use.
Sleutelkomponente:
- Double-Sided Mirror (1X and 30X magnification)
- LED ligring
- Touch Control Buttons (for power, light mode, and brightness)
- Verstelbare staander
- Stable Base with Storage Tray
- USB Type-C-laaipoort
- Tweezers (included accessory)
Opstelling
The mirror is designed for easy assembly and disassembly, making it convenient for both stationary use and travel.
Vergadering:
- Verify all three elements are present: the mirror head, the stand, and the base.
- Insert the stand into the base and turn clockwise until it locks securely.
- Attach the mirror head to the top of the stand until you hear a 'click' indicating it is fixed.
Image: Step-by-step guide for mirror assembly.
Disassembly for Travel:
- Plaas die spieël op 'n plat oppervlak.
- Pull the mirror head forward to detach it from the stand.
- Hold the stand and turn it counter-clockwise to remove it from the base.
Image: Instructions for disassembling the mirror for compact storage and travel.
Operasie
Krag aan/af:
Locate the touch control button on the mirror surface. A short touch will turn the LED light on or off.
Verstel van ligmodusse:
With the light on, short touch the control button to cycle through the three available light modes: Cool Light (6000K), Natural Light (4500K), and Warm Light (3000K).
Image: Visual representation of the three distinct light color modes.
Verstel van helderheid:
To adjust the brightness, long press the touch control button while the light is on. The brightness will seamlessly transition, allowing you to select your preferred intensity. Release the button when the desired brightness is reached.
Image: Illustration of continuous brightness adjustment via touch control.
Using Magnification:
The mirror features two sides: 1X for a standard view and 30X for detailed magnification. Rotate the mirror head to switch between the two sides. When using the 30X magnifying side, maintain a distance of approximately 10 cm (4 inches) from the mirror to achieve a clear image and avoid blurriness or dizziness. This is a normal physical phenomenon for high-magnification mirrors.
Image: Demonstrating the 1X and 30X magnification sides and the recommended usage distance for the 30X side.
360° rotasie:
The mirror head can be rotated 360 degrees horizontally to adjust to your preferred viewing angle. The stable base ensures the mirror remains steady during rotation.
Image: The mirror's 360-degree rotation feature for optimal viewhoeke.
Laai:
The mirror is equipped with a 2000mAh rechargeable lithium battery. Connect the included USB Type-C cable to the charging port on the mirror and to a compatible USB power source (e.g., computer, car charger, power bank, wall charger). A full charge takes approximately 3-5 hours and provides up to 15 hours of continuous use. The mirror also features a 30-minute auto-off function to conserve battery life.
Image: Detail of the USB Type-C charging port.
Phone Holder & Storage Tray:
The mirror's base includes a convenient storage tray for small items like jewelry or cosmetics. It also features a slot that can securely hold your smartphone, allowing for vertical video mode or widescreen theater mode while you use the mirror.
Image: The multi-functional base serving as a phone holder and storage tray.
Onderhoud
To ensure the longevity and optimal performance of your Auxmir mirror, follow these maintenance guidelines:
- Maak die spieëloppervlak skoon: Use a soft, lint-free cloth to gently wipe the mirror. For stubborn smudges, dampen the cloth slightly with water or a mild, non-abrasive glass cleaner. Avoid harsh chemicals or abrasive materials that could scratch the mirror or damage the LED lights.
- Cleaning the Body and Base: Wipe the ABS plastic body and base with a soft, dry cloth. If necessary, a slightly damp cloth can be used, but ensure no moisture enters the charging port or touch control areas.
- Berging: When not in use, especially for extended periods, store the mirror in a cool, dry place. If traveling, disassemble the mirror as instructed in the Setup section to protect its components.
- Batterysorg: To prolong battery life, avoid fully discharging the battery frequently. Recharge the mirror when the light dims or when the battery indicator suggests a low charge.
Probleemoplossing
If you encounter any issues with your Auxmir mirror, please refer to the following common problems and solutions:
| Probleem | Moontlike oorsaak | Oplossing |
|---|---|---|
| LED-lig skakel nie aan nie. | Battery is ontlaai. | Connect the mirror to a power source using the USB Type-C cable and charge for 3-5 hours. |
| LED light is dim or flickers. | Lae battery. | Herlaai die spieël. |
| Cannot change light mode or brightness. | Touch control malfunction or low battery. | Ensure the mirror is charged. Try a short press for mode change and a long press for brightness. If the issue persists, contact customer support. |
| Image is blurry or distorted on 30X side. | Verkeerd viewing afstand. | Maintain a distance of approximately 10 cm (4 inches) from the 30X magnifying mirror for a clear image. |
| Mirror head is loose or wobbly. | Onbehoorlike samestelling. | Ensure the mirror head and stand are securely attached and locked into the base as per assembly instructions. |
Spesifikasies
- Modelnommer: BM-2519
- Vergroting: 1X / 30X (Double-Sided)
- Spieël deursnee: 8 duim
- LED ligte: 64 LED's
- Ligmodusse: 3 (Cool, Natural, Warm)
- Helderheid: Dimbaar
- Battery: 2000mAh herlaaibare litiumbattery
- Laai tyd: 3-5 uur
- Deurlopende gebruik: Tot 15 uur
- Outo-af: 30 minute
- Rotasie: 360°
- Materiaal: Acrylonitrile Butadiene Styrene (ABS), Plastic, Glass
- Afmetings (L x B x H): 6.1 x 22.5 x 21.9 cm
- Gewig: 650 gram
- Ingesluit komponente: Magnifying Lighted Mirror, Tweezers, USB Type-C Charging Cable
Waarborg en Ondersteuning
Auxmir products are designed for quality and reliability. For warranty information, technical support, or any questions regarding your product, please refer to the contact information provided with your purchase or visit the official Auxmir webwebwerf. Bewaar asseblief u bewys van aankoop vir waarborgeise.
Produkvideo's
Watch the official product demonstration video to see the Auxmir mirror in action, highlighting its features and ease of use.
Video: A comprehensive demonstration of the Auxmir mirror's features, including light modes, brightness adjustment, magnification, rotation, and its multi-functional base.
