Aiwa MI-X330 Meteor Bluetooth Speaker User Manual

1. Inleiding

Thank you for choosing the Aiwa MI-X330 Meteor Bluetooth Speaker. This portable speaker is designed to deliver powerful audio with deep bass and clear sound, offering versatile connectivity and a long-lasting battery. Please read this manual carefully before using the product to ensure proper operation and to maximize your listening experience.

Figuur 1: Voorkant view of the Aiwa MI-X330 Meteor Bluetooth Speaker.

2. Produk verbyview

Sleutel kenmerke:

• Kragtige klankuitset: 60W high-quality audio with deep bass and crystal-clear sound.
• Veelvuldige verbindingsopsies: Supports Bluetooth, AUX, USB, and Mic input.
• Langdurige battery: 5000mAh heavy-duty Li-Ion battery with Type-C fast charging, providing 6 to 10 hours of playtime.
• Digitale skerm: Maklik view battery status, mode selection, and playback details.
• TWS Dual-Link Technology: Wirelessly pair two speakers for a powerful stereo sound experience.
• Premium Metallic Finish: Designed with a sleek and durable metallic build.

Luidspreker afmetings:

Figure 2: Aiwa MI-X330 Meteor Bluetooth Speaker with indicated dimensions.

3. Opstelling

3.1 Aanvanklike laai

1. Before first use, fully charge the speaker using the provided Type-C charging cable.
2. Connect the Type-C cable to the speaker's charging port and the other end to a compatible USB power adapter (not included).
3. The digital display will indicate charging status. Charging is complete when the battery indicator shows full.

3.2 Aan-/afskakel

• To power on, press and hold the Power button until the digital display illuminates.
• Om af te skakel, druk en hou die aan/af-knoppie weer in totdat die skerm afskakel.

4. Bedryfsinstruksies

4.1 Bluetooth -koppeling

1. Ensure the speaker is powered on and in Bluetooth mode (indicated on the digital display). If not, press the 'M' (Mode) button to switch to Bluetooth mode.
2. Aktiveer Bluetooth op jou mobiele toestel (slimfoon, tablet, ens.) en soek vir beskikbare toestelle.
3. Select "AIWA MI-X330 Meteor" from the list of devices.
4. Once paired, the speaker will emit an audible confirmation, and the display will show a stable Bluetooth icon.

4.2 TWS Dual-Link Technology (Pairing Two Speakers)

For a true stereo experience, you can pair two Aiwa MI-X330 Meteor speakers together.

1. Maak seker dat beide luidsprekers aangeskakel en in Bluetooth-modus is, maar nog nie met enige toestel gekoppel is nie.
2. On one of the speakers (this will be your primary speaker), press and hold the TWS button (refer to button layout on speaker).
3. The primary speaker will search for the secondary speaker. Once connected, both speakers will emit an audible confirmation.
4. Now, pair your mobile device with the primary speaker as described in Section 4.1. Audio will play in stereo through both speakers.

4.3 Ander konnektiwiteitsopsies

• AUX-invoer: Connect an external audio device using the provided AUX line cable to the speaker's AUX port. Press the 'M' button to switch to AUX mode.
• USB-invoer: Plaas 'n USB-flash drive wat oudio bevat files in die USB-poort. Die luidspreker sal outomaties na USB-modus oorskakel en begin met terugspeel.
• Mikrofoon-invoer: Connect a microphone to the Mic input port for karaoke or public address functions.

4.4 Kontroles

The speaker features intuitive controls for managing your audio.

• Kragknoppie: Druk en hou om aan/af te skakel.
• Mode ('M') Button: Short press to cycle through input modes (Bluetooth, AUX, USB).
• Speel/Pause-knoppie: Druk om oudio te speel of te onderbreek.
• Vorige/Volgende Snit-knoppies: Druk om na die vorige of volgende snit oor te gaan.
• Volumeknop: Draai om die algehele volumevlak aan te pas.
• Bas Knop: Draai om die basintensiteit aan te pas.

5. Laai en Battery

The Aiwa MI-X330 Meteor is equipped with a 5000mAh Li-Ion battery, offering extended playtime.

• Batterylewe: Provides approximately 6 to 10 hours of playtime, depending on volume level and audio content.
• Laai tyd: Varies based on the power adapter used. Use a compatible Type-C charger for optimal charging speed.
• Battery aanwyser: The digital display shows the current battery level. Charge the speaker when the indicator is low to prevent interruption.

6. Onderhoud

• Skoonmaak: Gebruik 'n sagte, droë lap om die buitekant van die luidspreker skoon te maak. Moenie skuurmiddels of oplosmiddels gebruik nie.
• Berging: Bêre die luidspreker op 'n koel, droë plek weg van direkte sonlig en uiterste temperature wanneer dit nie vir lang tye gebruik word nie.
• Waterweerstand: The product is not water resistant. Avoid exposure to water or high humidity.

7. Probleemoplossing

8. Spesifikasies

9. Wat is in die boks

Upon opening your Aiwa MI-X330 Meteor package, you should find the following items:

• Aiwa MI-X330 Meteor Bluetooth Speaker (1)
• Tipe C-laaikabel (1)
• AUX Line Cable (1)
• Gebruikershandleiding (1)
• Waarborgkaart (1)

10. Waarborg en Ondersteuning

Waarborginligting:

Hierdie produk kom met 'n 1 jaar waarborg from the date of purchase. Please refer to the included Warranty Card for detailed terms and conditions.

Kliëntediens:

For any support, queries, or service requests, please contact Aiwa customer service:

• Invoerder: AIWA INDIA SALES & SERVICES PRIVATE LIMITED
• Adres: 2E/26, Jhandewalan Extn, New Delhi -110055
• Kontaknommer: 1800-120-5619
• E-pos: getintouch@aiwaindia.com
